4.3.2. Type 1 Format (ARNAV format)
The Type 1 output sentences shall have the following general format:
Id item designator (single ASCII alphabetic character)
Dddd item data (1 to 10 printable ASCII characters)
CR ASCII carriage return character (0D hex)
LF ASCII line feed character (0A hex)
4.3.3. Shadin Formats (Altitude Sentence, Airdata Z, Airdata G, Airdata S)
Only Shadin S format has most of the data required to run the RosenView VX. Formats Z
and G do not have positional information, and none of the Shadin formats have
destination information.
4.4. Control Inputs
For controller information, access www.rosenaviation.com .
Click on the Products tab, and then select AccessoriesExt.
Controllers. Scroll down to view the RosenView external
controllers.
The RosenView VX IR receiver uses NEC-style 32-bit encoding. In this encoding format, there
are 16 bits of actual information transmitted as part of a 32-bit frame. The 16 bits of information
are divided into two parts: an 8-bit device code and an 8-bit function code.
Each 8-bit portion of the transmitted code is followed by the same code with each bit inverted.
Most IR remotes using this format will have the same device code for each button on the remote,
and a unique function code for each button.
Listed below are the default codes in hexadecimal format used with RosenView VX:
Table 6 Default codes used with the RosenView VX
Control Device Code Function Code
Enter Button: 0xE7 0x0D
Pan Up: 0xE7 0x08
Pan Down: 0xE7 0x09
Pan Left: 0xE7 0x11
Pan Right: 0xE7 0x10
Zoom In: 0xE7 0x52
Zoom Out: 0xE7 0x40
