Rosen Aviation RosenView VX Technical Manual
Document Number: 100640 Revision: G
Date: 9/19/12
Template: 4.4.1.6FM1; Revision A; 31 May, 2012 Page 12 of 23
4. SYSTEM CONNECTIONS
There are several ways to connect the RosenView VX to an aircraft’s data systems—either with
one of two ARINC-429 inputs or an RS-232 (GPS) input.
The 429 buses can be either low- or high-speed buses (the bus speed is auto-detected). The RS-
232 bus speed will auto-detect between 1200 to 9600 baud.
The labels on the ARINC bus are described below:
Data ARINC Label
UTC Time 125
GMT Time 150
Barro Corrected Altitude 204
Static Air Temp 213
Date 260
Present Position Latitude 310
Present Position Longitude 311
Ground Speed 312
Ground Track 313
True Heading 314
Wind Speed 315
Wind Angle 316
Distance To Destination 351
Time to Destination 352
Destination Local Time
Offset
353
Destination Airport ID 1* 365
Destination Airport ID 2* 366/364
Equipment ID 371
GAMA Flight Plan
Data Record Header 74
Active Wpt From/To 75
Record Checksum 113
Wpt Mess. Chars 7-9 301
Wpt Mess. Chars 10-12 302
Waypoint Type 303
Wpt Mess Chars 1-3 304**
Wpt Mess Chars 4-6 305**
Wpt Latitude 306
Wpt Longitude 307
* Rockwell Collins ’ Proline 21 only
** Rockwell Collins’ Proline series
To achieve at least basic operation, labels 125 or 150, 204, 260, 310, 311, 312, and 313 are
necessary. Additional labels will provide more information, for example Destination Airport,
Outside Air temperature, etc., but they will not be shown if they are not supplied.
