Rosen Aviation RosenView VX Technical Manual
Document Number: 100640 Revision: G
Date: 9/19/12
Template: 4.4.1.6FM1; Revision A; 31 May, 2012 Page 11 of 23
Table 4 VX Map remote control screen buttons
Button How it Works
Mode Opens a menu to select map viewing options. When the menu is open, press Mode
again to navigate the menu. Allow it to timeout to accept the selection. Where mode
was last is what you are selecting.
▲ ▼ ◄ ► Pans the map view north, south, west, or east.
OK Centers the map view on the aircraft’s location.
+ Zooms in on a map view. (Zoom times out after a pre-set time.)
– Zooms out on a map view. (Zoom times out after a pre-set time.)
Source Select 1 switches the output on display 1 — map, DVD, or auxiliary device.
Source Select 2 switches the output on display 2 — map, DVD, or auxiliary device.
3.4. VX DVD Screen
– Optional Remote
Table 5 VX DVD remote control screen buttons
Button How it Works
Eject ▲ Press once to eject or insert a disc. Allow the player time to eject the disc before
pressing eject again.
Menu Accesses the DVD menu or the DVD player’s setup menu if no disc is inserted.
▲ ▼ ◄ ► Navigates through a DVD’s menu options.
Play ► Plays the DVD.
Pause II Pauses the DVD.
Stop
■
Stops the DVD.
Previous I ◄ Reverses to previous chapter.
Fast Reverse
◄◄ Moves left in a menu. Hold in while a disc is playing to view previous scenes.
Continue to hold for different reverse speeds.
Fast Forward
►► Moves right in a menu, or hold in while a disc is playing to “fast forward.” Continue to
hold for different fast forward speeds.
Next ►I Advances to next chapter forward.
Enter Plays the menu option you select on the DVD.
Source Select 1 switches the output on display 1 — map, DVD, or auxiliary device.
Source Select 2 switches the output on display 2 — map, DVD, or auxiliary device.
