NTSC National Television Standards Committee; an analog video standard used in
the United States, Canada, Japan, Mexico, the Philippines, South Korea,
Taiwan, and some other countries
O&I Outline and Installation (drawing)
OSD On Screen Display – the actual user/technician menu, and any informational
readouts displayed on the image.
P/N Part Number
PAL Phase alternate (by) line – the analog video specification used by most
European countries and their former colonies world wide
PC Personal computer
RF Radio frequency
RS-232 Standard for serial binary data interchange
RTCA Radio Technical Commission for Aeronautics
SDI Serial Digital Interface
SECAM (Séquentiel couleur à mémoire; French for "sequential color with memory"),
an analog color video system first used in France
SMPTE Society of Motion Picture and Television Engineers – timecode frame rates
SHCS Socket head cap screw
TTL Taxiing, takeoff, and landing
V Volts
VDC Volts direct current
VGA Video Graphics Array
Vpp Volts peak-to-peak
W Watts
11. REVISION HISTORY
Revision E is limited to draft or prototype documents. Revisions I,
O, Q, S, X and Z are not to be used.
Revision Date Revision Description EC
A 10/09/13 Initial release 13-0370
B 04/17/14 Corrected CVBS Micro-D Base part numbers 14-0143
