Rosen Aviation 7” Widescreen Display
Document Number: 106211 Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12 Page 17 of 31
Pillar Box: A standard 4:3 source image will appear with vertical black bars on the left
and right side of the image. If the image source is letterboxed, then there will also be
horizontal bars at the top and bottom of the image as well.
Letter Box Expanded: Expands the source video in the vertical and horizontal
dimensions to fill the display screen. Letterbox-format DVDs will have small or no bars
showing in this mode, while 4:3 aspect video sources will expand beyond the screen
boundaries and appear cropped.
6.2.3. Scheme
There are two default color settings or schemes: Natural and Vivid. If the screen colors
are not what you expect, select Scheme and press + and
– to toggle between the
settings. The background picture
’s colors change as you toggle between the settings.
Vivid uses a higher color saturation level above the Natural level.
Try both schemes to determine which one you like best before adjusting the other picture
quality settings.
Select UserScheme and then press Menu to access the settings.
Select the setting and press Menu to accept the changes, and then select BackExit to
close the OSD.
6.3. Image Adjust Menu
Use the Image Adjust menu options, as shown below, to control the color and picture quality.
Highlight Image Adjust and press Menu to access the Image Adjust menu options.
Press + or – to select an Image Adjust option, and then press Menu to change its value.
Figure 18 Image Adjust menu options
6.3.1. Scheme
Scheme is also available from the Main MenuUser page. For information about how
this option works, see Section
6.2.3 , Scheme , on page 17 . Changing the Scheme also
affects changes that you make to the User menu settings and is source specific.
Picture-
quality
controls
