Quick Installation Guide
00825-0100-4075, Rev DA
July 2011
Smart Wireless THUM Adapter
7
Wiring Diagrams
The following is a list of the figure titles and page numbers for each direct mount and remote
mount wiring diagram:
Figure 6 - Direct Mount Wiring Diagram for 2-Wire Device on page 8
Figure 7 - Remote Mount Wiring Diagram for 2-Wire Device on page 8
Figure 8 - Direct Mount Wiring Diagram for 2-Wire Device with Resistor on page 9
Figure 9 - Remote Mount Wiring Diagram for 2-Wire Device with Resistor on page 9
Figure 10 - Direct Mount Wiring Diagram for 4-Wire Passive Device on page 10
Figure 11 - Remote Mount Wiring Diagram for 4-Wire Passive Device on page 10
Figure 12 - Direct Mount Wiring Diagram for 4-Wire Passive Device with Resistor on
page 11
Figure 13 - Remote Mount Wiring Diagram for 4-Wire Passive Device with Resistor on
page 11
Figure 14 - Direct Mount Wiring Diagram for 4-Wire Active Device on page 12
Figure 15 - Remote Mount Wiring Diagram for 4-Wire Active Device on page 12
Figure 16 - Direct Mount Wiring Diagram for 4-Wire Active Device with Resistor on page 13
Figure 17 - Remote Mount Wiring Diagram for 4-Wire Active Device with Resistor on
page 13
Figure 18 - Direct Mount Wiring Diagram for 4-Wire Active Device with No 4-20 mA Loop on
page 14
Figure 19 - Remote Mount Wiring Diagram for 4-Wire Active Device with No 4-20 mA Loop
on page 14
Figure 20 - THUM Adapter only, Powered by a 24 V Power Supply with 1200 Ohm resistor
to limit current to 20 mA on page 15
Figure 21 - THUM Adapter only, Powered by a 24 V Power Supply with 1200 Ohm resistor
to limit current to 20 mA on page 15
