Quick Installation Guide
00825-0100-4075, Rev DA
July 2011
Smart Wireless THUM Adapter
11
Figure 12. Direct Mount Wiring Diagram for 4-Wire Passive Device with Resistor
Figure 13. Remote Mount Wiring Diagram for 4-Wire Passive Device with Resistor
Splice Connector Wired Device
4-20 mA Loop -
4-20 mA Loop +
Ground
THUM Adapter
Green
Red
Black
White
Yellow
Po
w
e
r+
Po
w
e
r-
COMM
+
COMM
-
Load Resistor 250 
Power +
Supply -
Remote Mount Housing
4-20 mA Loop -
4-20 mA Loop +
Ground
+ COMM
- COMM
THUM Adapter
Green
Red
Black
White
Yellow
To Wired Device
Shield Wire
+ Power
- Supply
Load Resistor 250 
