14 Introduction
UM5C06D ( 169-2071-504 ) P0831010 Standard 7.00 May 2001
Figure 2 - MPS75 Modular Power shelf- NT5C10C with 26-pin signal connectors
Mounting
holes (4)
Signal cable connection
DC connection
Mounting
holes (4)
Figure 3 - NT5C06D Switch Mode Rectifier
Height:
168 mm (6.60 inches)
Depth:
260 mm (10.25 inches)
Width:
149 mm (5.85 inches)
Weight:6.8 kg (15 lbs)
EQL
FLT
FAN
HVSD
ON RFA
D C
CC
OUTPUT
V+
V-
SO RTIE
LOA D
CHARG E
3MA 250V
F1
A C
CA
MPR25
MPR15
