Serial Communication, cont’d
DVS 304 • Serial Communication 3-12
Command/response table for SIS commands (continued)
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional description
Audio mute (audio models only)
Mute on 1Z Amt1] Mute selected input.
Mute off 0Z Amt0] Un-mute selected input.
View status Z X8) ] View mute status
(0= mute off, 1= mute on).
Audio gain and attenuation (audio models only)
N The set gain (G) and set attenuation (g) commands are case sensitive. The increment, decrement, and view commands are not.
N Add a leading 0 when it is a single digit value
Specific gain X10@ G Aud X10@ ] Set gain to X10@ dB.
Set attenuation X10# g Aud X10# ] Set attenuation to X10# dB.
Increment +G Aud X10! ] Increment audio level (up).
Decrement - G Aud X10! ] Decrement audio level (down).
View G X10! ] View current audio level.
Volume control (audio models only)
Specific volume X10$ V Vol X10$ ] Set volume to X10$ .
Increment +V Vol X10$ ] Increase volume.
Decrement - V Vol X10$ ] Decrease volume.
View V X10$ ] View current volume setting.
Test Pattern
N These commands are not case sensitive. Both (J) and (j) can be used interchangeably.
Crop 1J Tst 1] Set crop test pattern on.
Alternating pixels 2j Tst 2] Set alternate pixels on.
Color bars 3J Tst 3] Set color bars on.
Off 0J Tst 0 ] Set test pattern off.
View Test Pattern J X10$ ] View the test pattern.
Freeze
N These commands are not case sensitive. Both (F) and (f) can be used interchangeably
Enable 1f Frz 1] Freeze selected input.
Disable 0F Frz 0] Unfreeze selected input.
View F X8) ] Show the freeze status (1= on, 0=
off).
RGB delay time
Set RGB Delay 3* X10& # Dly X10& ] Set RGB delay to ( X10& x 0.5)
seconds.
View setting 3# X10& ] View RGB delay setting.
N X8) = 0 or 1
X10! = Audio level adjustment range: -15 to +9 dB
X10@ = Audio gain adjustment range: 0 to 9 dB
X10# = Audio attenuation adjustment range: -15 to 0 dB
X10$ = Volume range: 000 to 100 (always returns 3 digits)
X10& = RGB delay: 0 to 10 (0 to 5 seconds in 0.5 second steps )
