Serial Communication, cont’d
DVS 304 • Serial Communication
3-10
Command/response table for SIS commands (continued)
Command
ASCII Command
(host to scaler)
Response
(scaler to host)
Additional description
Contrast
Specific value
X8%
^
Con
X8%
]
Sets contrast level to
X8%
.
Increment up
+ ^
Con
X8%
]
Increments contrast level.
Increment down
– ^
Con
X8%
]
Decrements contrast level.
View
^
X8%
]
View current setting.
Brightness
Specific value
X8%
Y
Brt
X8%
]
Sets brightness level to
X8%
.
Increment up
+ Y
Brt
X8%
]
Increments brightness level.
Increment down
– Y
Brt
X8%
]
Decrements brightness level.
View
Y
X8%
]
View current setting.
Detail Filter
Set detail level
X8%
D
Shp
X8%
]
Specify the detail level to
X8%
.
Increment up
+ D
Shp
X8%
]
Increase the detail level.
Increment down
– D
Shp
X8%
]
Decrease the detail level.
View detail value
D
X8%
]
Show the detail setting.
Horizontal Shift
Specific value
X8^
H
Hph
X8%
]
Set horizontal centering to
X8%
.
Increment up
+ H
Hph
X8%
]
Shift window right.
Increment down
– H
Hph
X8%
]
Shift window left.
View
H
X8%
]
Horizontal centering value is
X8%
.
Vertical Shift
Specific value
X8^
/
Vph
X8^
]
Set vertical centering to
X8^
.
Increment up
+ /
Vph
X8^
]
Shift window down.
Increment down
– /
Vph
X8^
]
Shift window up.
View
/
X8^
]
Vertical centering value is
X8^
.
Horizontal Size
Specific value
X8&
:
Hsz
X8&
]
Set horizontal sizing to
X8&
.
Increase Size
+:
Hsz
X8&
]
Widen the window.
Decrease Size
–:
Hsz
X8&
]
Make the window narrower.
View
:
X8&
]
Horizontal sizing value is
X8&
.
Vertical Size
Specific value
X8&
;
Vsz
X8&
]
Set vertical sizing to
X8&
.
Increase Size
+;
Vsz
X8&
]
Make the window taller.
Decrease Size
–;
Vsz
X8&
]
Make the window shorter.
View
;
X8&
]
Vertical sizing value is
X8&
.
N
X8%
= Picture adjustment:
0 to 127
X8^
= H and V position
Values depend on current output rate
X8&
= H and V size
Values depend on current output rate
X8*
= Zoom
100 to 200%
