AC RapidP
ak
Heavy Duty 460 VAC, 3-Phase Input and Output, 50/60 Hz Input
Heavy Duty
150% for 1 minute
Slim Enclosure Cube Enclosure
Order Code
Dimensions
HxWxD (in)
Weight
(Ibs)
Order Code
Dimensions
HxWxD (in)
Weight
(Ibs) HP Amps
1 2.1 RSxxH4001xxx-x 38x16x16 135 RCxxH4001xxx-x 24x16x16 70
1.5 3 RSxxH41P5xxx-x 38x16x16 135 RCxxH41P5xxx-x 24x16x16 70
3 5.8 RSxxH4003xxx-x 38x16x16 135 RCxxH4003xxx-x 24x16x16 70
5 7.6 RSxxH4005xxx-x 38x16x16 135 RCxxH4005xxx-x 24x16x16 70
7.5 13 RSxxH47P5xxx-x 38x16x16 135 RCxxH47P5xxx-x 24x16x16 70
10 16.5 RSxxH4010xxx-x 38x16x16 140 RCxxH4010xxx-x 24x16x16 70
15 25 RSxxH4015xxx-x 38x16x16 140 RCxxH4015xxx-x 24x16x16 70
20 29 RSxxH4020xxx-x 38x16x16 140 RCxxH4020xxx-x 24x16x16 70
25 32 RSxxH4025xxx-x 56x16x16 140 RCxxH4025xxx-x 30x24x16 70
30 40 RSxxH4030xxx-x 56x16x16 210 RCxxH4030xxx-x 30x24x16 150
40 60 RSxxH4040xxx-x 72x21x16 210 RCxxH4040xxx-x 39x30x16 150
50 74 RSxxH4050xxx-x 72x21x16 300 RCxxH4050xxx-x 39x30x16 250
75 96 RSxxH4075xxx-x 72x21x16 300 RCxxH4075xxx-x 39x30x16 280
100 124 RSxxH4100xxx-x 72x36x18 550
n/a 125 156 RSxxH4125xxx-x 72x36x18 550
150 180 RSxxH4150xxx-x 90x36x20 700
AC RapidPaks are available with Commander SK, Commander GP20 and Unidrive SP
Definition - RapidPak AC Order Code Configurator
Item Description
Enclosure Style
C = Cube enclosure
S = Slimline enclosure Cube enclosure option allows only the circuit breaker, non-fused disconnect switch and door operator devices.
The Slimline enclosure allows all the options unless bypass is selected, then there is a limit of either an input or
output reactor.
Drive Type
SKN = SK Normal Duty, SKH = SK Heavy Duty,
CGN = GP20 Normal Duty, CGH = GP20 Heavy Duty,
SPN = SP Normal Duty, SPH = SP Heavy Duty,
Three drive models: Commander SK, Commander GP20 & Unidrive SP, AC drives with a Normal duty, current
overload rating of 110% for 60 seconds. Heavy duty, current overloads rating of 150% for 1 minute.
Voltage Rating
8=208 VAC, 2=230 VAC, 3=380 VAC, 4=460 VAC
AC Input line voltage, 3 hp, 50/60 Hz, equals AC output rating for motor.
HP Rating Motor hp ratings are based on typical motor current ratings. Actual motor currents and the type of applications
should be reviewed before selecting drive size.
Door Mounted Operator Station
0 = Blank
1 = Stop PB, Start PB, Fault Light, Pot.
2 = # 1 & Jog PB, Fwd/Rev SS
3 = # 2 & Power On Light
4 = HOA SS, Pot, Power On, VFD Run, Fault Light
5 = HOA SS, Plus Bypass
The blank option defines that the devices are remote mounted. Selection #1 to #5 defines that the devices are
door mounted and wired to the drive terminals.
Input Power
0 = Main Lugs with Input Fusing
1 = Circuit breaker (CB)
2 = Non-fused disconnect (NFD) 0 = Input Main lugs for customer termination with input fusing standard.
1 = CB with through the door operator, Thermal-magnetic overload protection and main circuit disconnect.
Includes drive input semiconductor fuses.
2 = NFD with through the door operator, main circuit disconnect. Includes drive fusing.
Note: Weight does not include options.
