Unidrive SPMs
Output Module Selection
DC Fuse Selection
Input Module Selection
AC Fuse Selection
Drive
Normal Duty
Heavy Duty
24 VDC
Input
[3]
Controlled
Uncontrolled
24V DC
Input
[3]
Max
Cont.
Current
Typical
Motor
Output
Max
Cont.
Current
Typical
Motor
Output
Single
Dual
Single
[3]
Dual
[3]
Order
Code
A
220V
kW
230V
hp
A
220V
kW
230V
hp
A
A
A
A
200-
240 VAC
+/- 10%
SPMD1201
192
55
75
156
45
60
3.3
400
na
na
SPMU1402 SPMU2402
3.0
400
SPMD1202
248
75
100
192
55
75
3.3
550
na
na
SPMD1203
312
90
125
250
75
100
5.0
550
na
na
SPMD1204
350
[1]
110
[1]
150
[1]
290
90
125
5.0
550
na
na
A
400V
kW
400V
hp
A
400V
kW
400V
hp
380-
480 VAC
+/- 10%
SPMA1401
205
110
150
180
90
150
3.3
na
na
na
na
na
na
315
SPMA1402
236
132
200
210
110
150
3.3
na
na
na
na
na
na
350
SPMD1401
205
110
150
180
90
150
3.3
400
SPMC1402 SPMC2402 SPMU1402 SPMU2402
3.0
400
SPMD1402
246
132
200
210
110
150
3.3
560
SPMD1403
290
160
250
246
132
200
5.0
560
SPMD1404
350
[1]
200
[1]
300
[1]
290
160
250
5.0
560
A
575V
kW
575V
hp
A
575V
kW
575V
hp
500-
575 VAC
+/- 10%
SPMA1601
[2]
125
90
125
100
75
100
3.3
na
na
na
na
na
na
200
SPMA1602
[2]
144
110
150
125
90
125
3.3
na
na
na
na
na
na
200
SPMD1601
[2]
125
90
125
100
75
100
3.3
250
SPMC1601 SPMC2601 SPMU1601 SPMU2601
3.0
250
SPMD1602
[2]
144
110
150
125
90
125
3.3
315
SPMD1603
[2]
168
110
150
144
110
150
5.0
350
SPMD1604
[2]
192
150
200
168
110
150
5.0
400
A
600V
kW
600V
hp
A
600V
kW
600V
hp
500-
690 VAC
+/- 10%
SPMA1601
125
110
150
100
90
125
3.3
na
na
na
na
na
na
200
SPMA1602
144
132
175
125
110
150
3.3
na
na
na
na
na
na
200
SPMA1601
125
110
150
100
90
125
3.3
250
SPMC1601 SPMC2601 SPMU1601 SPMU2601
3.0
250
SPMA1602
144
132
175
125
110
150
3.3
315
SPMA1603
168
160
200
144
132
175
5.0
350
SPMA1604
192
185
250
168
160
200
5.0
400
Normal Duty
Suitable for most applications, current overload
is set at 110% for 60 seconds. Where motor
rated current is less than the drive continuous
current, higher overloads are achieved.
Heavy Duty
(Rotor Flux
Control and
Closed Loop)
Suitable for demanding applications, current
overload is set at up to 150% for 60 seconds.
Where motor rated current is less than the
drive rated continuous current overloads
(200% or greater) are achieved.
Notes:
[1] The full rating is only possible when the SPMD is mounted separately to the SMPC.
That is, a single module can deliver 350A with a separate airflow path for each module
and Tambient = <35°C. Otherwise the limit is 335A.
[2] The same model can be used on a 575V or a 690V supply and has two different output
ratings. e.g. At Normal Duty, SPMD1601 is suitable for a 90 kW output motor on a 575V
but is suitable for a 110 kW output motor on 690V.
[3] All SPM modules require a 24 VDC power supply for the cooling fans. The total
24 VDC current required can be assessed in the table and a 24 VDC supply chosen.
[4] For paralleling, the necessary interface cable that connects a follower to a master
or another follower is delivered with the follower module.
[5] A separate soft start must be provided for the DC link. Please contact your supplier.
[6] Input inductance may be incorporated in star-delta transformer.
[7] Only 400A AC and DC fuses are stocked by Control Techniques, as
these are used with other products.
[8] For more information, contact your supplier.
SPM D 1 4 0 1 - 4 T
Modular power stages
for custom drive systems
Module Type (a)
A - AC in AC drive out put
D - DC in AC drive output
C - Controlled rectifier input
U - Uncontrolled rectifier input
Top level code
Design requirement
T - 12 pulse S - Simple Install
L - Lowest Cost
R - Regen or Active Input
Module Type (b)
1 - Single rectifier 2 - Dual rectifier
Top level code- Multiple modules
M - Single master S - Single follower
2-10 - Number of parallel drives
Current Rating Step
Voltage Rating
2 - 200V to 240V 4 - 380V to 480V
5 - 500V to 575V 6 - 500V to 690V
Configuration (SPMA and D only)
0 - Dynamic brake control
2 - No dynamic brake controls
Option Reference
Order Code
SM-Control Master
SM-Control Master
SM-Control Follower
SM-Control Follower
[4]
24V DC Supply - 10A
8510-0000
SPM Docking Kit
3470-0012
