Order String
Model
Normal Duty Rating (110%) Heavy Duty Rating (150%)
hp
460 VAC
Continuous
Amps
Peak Amps
hp
460 VAC
Continuous
Amps
Closed Loop
Peak Amps
LESPx4100 100 138 151 100 124 217
LESPx4125 125 168 184 125 156 273
LESPx4150 150 205 226 150 210 315
LESPx4200 200 236 260 200 246 369
LESPx4250 250 290 319 250 290 435
LESPx4300 300 335 369 300 342 513
LESPx4350 350 448 492 350 399 599
LESPx4400 400 470 517 400 470 682
LESPx4450 450 551 606 450 551 827
LESPx4500 500 637 701 500 599 898
L E XXX X XXX X X X - XXXXX
Product
L = Large Enclosed Drive
Package Type
E = NEMA 12 Enclosure
Drive Model
SPN= SP Normal Duty
SPH= SP Heavy Duty
Voltage Rating
8 = 208 VAC (future)
2 = 230 VAC (future)
3 = 380 VAC (future)
4 = 460 VAC
Horsepower Rating
100 = 100 hp 125 = 125 hp
150 = 150 hp 200 = 200 hp
250 = 250 hp 300 = 300 hp
350 = 350 hp 400 = 400 hp
450 = 450 hp 500 = 500 hp
Options
0 = None
1 = AC Input Reactor (2)
2 = AC Output Reactor (3)
5 = Blower Motor Starter
F = Nema-3R Enclosure (future)
Input Power
0 = Main Lugs (1)
1 = Thru Door Disconnect Circuit Breaker(1)
2 = Thru Door Non-Fused Disconnect Switch(1)
Door Mounted Keypad
0 = LED Keypad on drive
K = LCD Keypad mounted on door
N = LCD Keypad on drive
Door Mounted Operator Station
0= No Operators
1 = Stop PB, Start PB, Fault Lamp, Potentiometer
2 = #1 + Jog PB, Fwd/Rev SS
3 = #2 + Power On Lamp
4 = HOA SS, Power On Lt, VFD Run,
Fault Lamp, Potentiometer
460 VAC Large Enclosed Drives Horsepower Ratings
Maximum permissible current output @ 40°C and 3kHz switching frequency. Consult factory for higher horsepower drives.
(1) Drive line fuses are included as standard
(2) Input reactors are included on 200 hp HD, and all 250 to 500 hp drives
(3) Output reactors are included on all 300 to 500 hp drives Ordering Notes:
