DC RapidP
ak
Non-Regenerative 208-240-380-480 VAC, 3-Phase Input, 50/60 Hz
QuantumPak: Panel or N12 (PPBF) Enclosure, DC Drive, 120 VAC CPT, DC contactor with DB contact, Input fusing.
HP
240 VDC
HP
500 VDC
Armature Amps @
Field Amps
Panel
Order Code
Enclosure
Order Code
40 ˚ C
55 ˚ C
3-10
5-20
n/a
38
Max 8A
Field Current
Regulator
DPNx038B0-x
DENx038B0-x
15
25-30
55
DPNx055B0-x
DENx055B0-x
20-30
40-60
106
DPNx106B0-x
DENx106B0-x
40-50
75-100
172
DPNx172B0-x
DENx172B0-x
MentorPak: Panel or N12 (PPBF) Enclosure, DC Drive, 120VAC CPT, AC Input contactor without DB contact, Input fusing.
HP
240 VDC
HP
500 VDC
Armature Amps @
Field Amps
Panel
Order Code
Enclosure
Order Code
40 ˚ C
55 ˚ C
60
125
210
Call
Factory
Max 8A Field
Current Regulator
DPNx210A0-x
DENx210A0-x
75
150
255
Max 10A
Fixed Field
Supply
DPNx255A0-x
DENx255A0-x
100
200
350
DPNx350A0-x
DENx350A0-x
125
250
420
DPNx420A0-x
DENx420A0-x
150
300
550
DPNx550A0-x
DENx550A0-x
200
400
700
DPNx700A0-x
DENx700A0-x
500
825
DPNx825A0-x
DENx825A0-x
Notes:
1) HP rating is a guide, please verify the motor armature amps at 40° or 55° C, then select the drive amps to be equal or greater then the motor amps.
2) The voltage code suffix is the 4th digit in the order string.
Regenerative 208-240-380-480 VAC, 3-Phase Input, 50/60 Hz
QuantumPak: Panel or N12 (PPBF) Enclosure, DC Drive, 120 VAC CPT, DC contactor with DB contact, Input fusing.
HP
240 VDC
HP
500 VDC
Armature Amps @
Field Amps
Panel
Order Code
Enclosure
Order Code
40 ˚ C
55 ˚ C
3-10
15-20
n/a
38
Max 8A
Field Current
Regulator
DPRx038B0-x
DERx038B0-x
15
25-30
55
DPRx055B0-x
DERx055B0-x
20-30
40-60
106
DPRx106B0-x
DERx106B0-x
40-50
100
172
DPRx172B0-x
DERx172B0-x
MentorPak: Panel or N12 (PPBF) Enclosure, DC Drive, 120 VAC cntrl logic, AC Input contactor without DB contact, Input fusing.
HP
240 VDC
HP
500 VDC
Armature Amps @
Field Amps
Panel
Order Code
Enclosure
Order Code
40 ˚ C
55 ˚ C
60
125
210
Call
Factory
Max 8A Field
Current Regulator
DPRx210A0-x
DERx210A0-x
75
150
255
Max 10A
Fixed Field
Supply
DPRx255A0-x
DERx255A0-x
100
200
350
DPRx350A0-x
DERx350A0-x
125
250
420
DPRx420A0-x
DERx420A0-x
150
300
550
DPRx550A0-x
DERx550A0-x
200
400
700
DPRx700A0-x
DERx700A0-x
500
825
DPRx825A0-x
DERx825A0-x
Dimensions & Weights
Armature
Amps @
Dimensions
H x W x D (inches)
Weights
(lbs)
40˚ C
55˚ C
Panel
Enclosure
Panel
Enclosure
n/a
38
33x27x13
36x30x16
75
170
55
106
172
210
Call
Factory
255
45x33x12
48x36x16
125
400
350
420
60x32x14
72x36x18 or
90x36x20 with NFD
210
600
550
700
825
Note: Package Size 2, when adding the FXM5 option to the panel or enclosure the package size changes to Size 3.
