Using Built-in Tones (Tutorial)
E-23
■ Editable SYSTEM Parameters
• Parts 5 through 16 do not support use of resonance
effects.
System Chorus
Parameter Value Ranges:
1 :Type (Light Cho, Chorus, FB Chorus, Flanger)
Selects the chorus type.
2 :LFO Rate (0 to 127)
Adjusts the LFO rate.
3 :LFO Depth (0 to 127)
Adjusts the LFO depth.
4 :Feedback (0 to 127)
Adjusts the feedback amount.
5 :Tone (0 to 127)
Adjusts the tone.
6 :Delay Time (0 to 127)
Adjusts the delay time.
7 :Delay Send (0 to 127)
Adjust the send level to system delay.
8 :Reverb Send (0 to 127)
Adjust the send level to system reverb.
9 :Return (0 to 127)
Adjusts the return level.
System Delay
Parameter Value Ranges:
1 :Time (0 to 127)
Adjusts the total delay time.
2 :Feedback (0 to 127)
Adjusts the feedback amount of the center channel.
3 :High Damp (0 to 127)
Adjusts the high-range damp. A smaller number increases
damping.
4 :Ratio L (0 to 127)
Adjusts the ratio of the left channel relative to the total delay time.
5 :Ratio C (0 to 127)
Adjusts the ratio of the center channel relative to the total delay
time.
6 :Ratio R (0 to 127)
Adjusts the ratio of the right channel relative to the total delay
time.
7 :Level L (0 to 127)
Adjusts the level of the left channel.
8 :Level C (0 to 127)
Adjusts the level of the center channel.
9 :Level R (0 to 127)
Adjusts the level of the right channel.
10 :Tempo Sync (Off, 1/4, 1/3, 3/8, 1/2, 2/3, 3/4, 1, 4/3, 3/2, 2)
Specifies how the actual total delay time is synced with tempo.
• Off: Uses Delay Time value.
• 1/4 to 2: Uses value in accordance with number of beats.
11 :Reverb Send (0 to 127)
Adjust the send level to system reverb.
12 :Return (0 to 127)
Adjusts the return level.
System Reverb
Parameter Value Ranges:
1 :Type (Room, Hall1, Hall2, Plate)
Selects the reverb type.
2 :Time (0 to 127)
Adjusts the reverb time.
3 :Early Reflection (0 to 127)
Adjusts the level of the initial reflection.
4 :High Damp (0 to 127)
Adjusts the high-range damp. A smaller number increases
damping.
5 :Tone (0 to 127)
Adjusts the tone.
6 :Return (0 to 127)
Adjusts the return level.
System Resonance
Parameter Value Ranges:
1 :String Reso Send (0 to 15)
Adjusts the send level to string resonance.
2 :Damper Reso Send (0 to 15)
Adjusts the send level to damper resonance.
3 :Damper Noise Enable (Off, On)
Enables/disables the damper noise effect.
■ Editable MASTER Parameters
Master Compressor
Parameter Value Ranges:
1 :Threshold (0 to 127)
Adjusts the threshold (where application of an effect starts) level.
Set a lower value for a compressor effect, and a higher value for a
limiter effect.
2 :Ratio (0 to 127)
Adjusts the compression ratio.
Set a lower value to for a compressor effect, and the maximum
value to for a limiter effect.
3 :Level (0 to 127)
Adjusts the output level.
4 :Attack (0 to 127)
Adjusts the time until the compression effect starts.
A smaller value causes prompt compressor operation, which
suppresses the attack of the input signal. A larger values delays
compressor operation, which causes the attack of the input signal
to be output as-is.
5 :Release (0 to 127)
Adjusts the release time.
Adjusts the time until the compression effect is released.
6 :Position (PreEQ, PostEQ)
Selects the connection position with the compressor and EQ.
Master Equalizer
Parameter Value Ranges:
1 :Low Gain (–12 to 0 to +12)
Adjusts the low-range gain.
2 :Low Frequency (200, 400, 800 [Hz])
Selects the low-range cutoff frequency.
3 :Mid 1 Gain (–12 to 0 to +12)
Adjusts the low mid-range gain.
4 :Mid 1 Frequency
(1.0k, 1.3k, 1.6k, 2.0k, 2.5k, 3.2k, 4.0k, 5.0k [Hz])
Selects the low mid-range frequency.
5 :Mid 2 Gain (–12 to 0 to +12)
Adjusts the high mid-range gain.
6 :Mid 2 Frequency
(1.0k, 1.3k, 1.6k, 2.0k, 2.5k, 3.2k, 4.0k, 5.0k [Hz])
Selects the high mid-range frequency.
7 :High Gain (–12 to 0 to +12)
Adjusts the high-range gain.
8 :High Frequency (6.0k, 8.0k, 10k [Hz])
Selects the high-range cutoff frequency.
9 :Input Level (0 to 127)
Adjusts the input level.
10 :Output Level (0 to 127)
Adjusts the output level.
