Power and Control Wiring
11
For preparation purposes, the following tables provide the dimensions and wire sizes for the input
junction boxes.
Table 3
Input junction box dimensions
Switch Rating
Length
Inches (mm)
Width
Inches (mm)
Height
Inches (mm)
100 amp
16 (406)
14 (356)
6 (152)
250 to 600 amp
30 (762)
16 (406)
6 (152)
Table 4
Input junction box terminal wire size range
Switch Rating
Power and Ground Lug Wire Range
100 amp
#6 to #2/0 AWG
250 to 600 amp
(2) #6 AWG to (2) 500 kcmil
