128
128 | Control Panel Summary
Menu Setting Summary
Press the Menu button to enter menu mode and select the settings
summarized here.
Menu setting Description
PRINTER SETUP menu
PLATEN GAP Adjusts the distance from the print head to the
paper; see page 69 for details.
NARROW for thin paper
STANDARD for most printing
WIDE or WIDER if images are smeared
WIDEST for thick paper
PAGE LINE Selects whether to print a cut off line between
pages on roll paper; see page 56 for details.
ROLL PAPER MARGIN Selects the margins for roll papers.
DEFAULT (15 mm all around)
TOP/BOTTOM 15 mm (3 mm left/right)
TOP 35/BOTTOM 15 mm (3 mm left/right)
3 mm (all around)
15 mm (all around)
PAPER SIZE CHECK Selects whether the printer checks to see if the
width of the loaded paper matches the width
selected in your print job (ON is recommended).
PAPER SKEW CHECK Selects whether the printer alerts you if paper is
not feeding straight by displaying PAPER SKEW
on the LCD display and stopping printing. If you
select
OFF , you do not receive an error even if the
print job is out of range of the loaded paper.
AUTO NOZZLE CHECK Selects whether to automatically check the print
head nozzles periodically or before printing each
print job.
PRINT NOZZLE PATTERN Selects whether to print a nozzle check pattern on
every page or every 10 pages.
AUTO WT INK REFRESH Selects whether the printer replaces white ink
with cleaning fluid at certain times (ON is
recommended).
INITIALIZE SETTINGS Resets the PRINTER SETUP menu settings to
their default settings.
