12 Technical Data
SI 3324 SI 4248
Output data:
Nominal AC voltage (V
AC, nom
) (adjustable) 230 V (202 to 253 V) 230 V (202 to 253 V)
Nominal frequency (f
nom
) 50 Hz 50 Hz
Continuous AC output (P
nom
) at 25°C 3300 W 4200 W
Continuous AC output (P
nom
) at 45°C 2300 W 3400 W
AC output for 30 min at 25°C 4200 W 5400 W
AC output for 5 min at 25°C 4400 W 6200 W
AC output for 1 min at 25°C 5000 W 7000 W
Nominal AC current (I
AC, nom
) 14.5 A 18 A
Max. current (peak value) for 100 ms 100 A (100 ms) 100 A (100 ms)
Harmonic distortion of output voltage
(K
VAC
)
< 3 % < 3 %
Phase shift factor cosϕ -1 to +1 -1 to +1
Input data
Input voltage (V
AC, ext
) (adjustable) 230 V (172.5 to 250 V) 230 V (172.5 to 250 V)
Input frequency (f
ext
) (adjustable) 50 Hz (40 to 60 Hz) 50 Hz (40 to 60 Hz)
Max. AC input current (I
AC, ext
)
(adjustable)
56 A (2 to 56 A) 56 A (2 to 56 A)
Max. input power (P
AC, ext
) 12.8 kW 12.8 kW
Battery data
Battery voltage (V
Bat, nom
) (adjustable) 24 V
DC
(21 to 32 V
DC
) 48 V
DC
(41 to 63 V
DC
)
Max. battery charging current (I
Bat, max
) 140 A
DC
100 A
DC
Continuous charging current (I
Bat, nom
) 104 A
DC
80 A
DC
Battery capacity 100 to 6000 Ah 100 to 6000 Ah
Charge control IV
0
V process with
automatic full and
equalization charge
IV
0
V process with automatic
full and equalization charge
Efficiency/power consumption
Max. efficiency (typical) 94,5 % 95 %
Own consumption (no load/standby) 22 W (< 4 W) 22 W (< 4 W)
German standards
DIN EN 50178,
DIN EN 61000-3-2 (when
charging),
DIN EN 61000-6-1,
DIN EN 61000-6-2,
DIN EN 61000-6-3,
DIN EN 61000-6-4 DIN EN 50178,
DIN EN 61000-3-2 (when
charging),
DIN EN 61000-6-1,
DIN EN 61000-6-2,
DIN EN 61000-6-3,
DIN EN 61000-6-4
