Parameter Lists
User Manual
SI3324/4248-14:FE2406
Page 49
10.2 Displayed Measurement Values
Inverter Meters
Battery Meters
No.
Name
Range/
unit
Default
Description
11-1
VacInverter
0 to 300 VAC
N/A
Inverter output voltage
11-2
AmpacInverter
-70 to +70 AAC
N/A
Inverter output current
11-3
FacInverter
0 to 70 Hz
N/A
Inverter frequency
11-4
PacInverter
-10,000 to
+10,000 W
N/A
Inverter AC output power
No.
Name
Range/unit
Default
Description
12-1
BatVoltage
0 to 80 VDC
N/A
Battery voltage
12-2
BatCurrent
-200 to +200 ADC
N/A
Battery current
12-3
BatTemp
-40 to +200°C
N/A
Battery temperature
12-4
BatState
Normal Warning
Low
Critical
N/A
Battery state
12-5
BatChargeMode
Boost
Full
Float
Equalize
N/A
Battery charging process
12-6
TabsorbLeft
0 to max min
N/A
An absorption period is assigned to every
charging process. The Sunny Island 3324/
4248 must keep the generator running
during this time, even when this is only
partially loaded. The value of
"TabsorbLeft" shows the time remaining for
the absorption phase.
12-7
BatChargeVolt
SI 4248
44 to 62.4 VDC
Desired value of the battery charging
voltage
SI 3324
27 to 31.2 VDC
