10 Decommissioning
10.1 Removing the Sunny Boy
1. Open the Sunny Boy as described in section 7.1 "Opening the Sunny Boy" (page 32).
2. Remove all cables from the Sunny Boy.
3. Close the Sunny Boy: fasten the enclosure lid to the Sunny Boy with the 4 screws.
4. Loosen the lower screw between the Sunny Boy
und wall mounting bracket.
5. Remove the Sunny Boy from the wall mounting
bracket.
☑ The Sunny Boy has been removed.
CAUTION!
Risk of injury due to the heavy weight of the Sunny Boy!
• Take the weight of the Sunny Boy of approx. 25 kg into account.
