Opening programs and entering 3.2
3
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
105
WORKPIECE BLANK DEF.: MINIMUM
Enter in sequence the X, Y and Z coordinates of
the MIN point and confirm each of your entries
with the ENT key
WORKPIECE BLANK DEF.: MAXIMUM
Enter in sequence the X, Y and Z coordinates of
the MAX point and confirm each of your entries
with the ENT key
Example: Display the BLK form in the NC program
0 BEGIN PGM NEW MM Program begin, name, unit of measure
1 BLK FORM 0.1 Z X+0 Y+0 Z-40
Spindle axis, MIN point coordinates
2 BLK FORM 0.2 X+100 Y+100 Z+0
MAX point coordinates
3 END PGM NEW MM Program end, name, unit of measure
The TNC automatically generates the block numbers as well as the
BEGIN and END blocks.
If you do not wish to define a blank form, cancel the
dialog at
Working plane in graphic: XY by pressing
the DEL key.
