HEIDENHAIN TNC 320 (340 55x-04) - Manual (Page 495)

HEIDENHAIN TNC 320 495
Comparison: Differences in MDI operation
Comparison: Differences in programming
station
Function TNC 320 iTNC 530
Execution of connected sequences Function partially available Available function
Saving modally effective functions Function partially available Available function
Function TNC 320 iTNC 530
Demo version Programs with more than 100 NC
blocks cannot be selected, an error
message is issued Programs can be selected, max. 100
NC blocks are displayed, further blocks
are truncated in the display
Demo version If nesting with PGM CALL results in
more than 100 NC blocks, there is no
test graphic display; an error message
is not issued Nested programs can be simulated.
Copying NC programs Copying to and from the directory TNC:\
is possible with Windows Explorer TNCremo or file manager of
programming station must be used for
copying.
Shifting the horizontal soft-key row Clicking the soft-key bar shifts the
soft-key row to the right, or to the left Clicking any soft-key bar activates the
respective soft-key row.
