Grass Valley Thunder 80 v.1.0 - Manual (Page 20)

Intercom Modules
Intercom Format Part Number
Intercom module - 4 wire each end ADDR-AUX-4W
Intercom module - ClearCom each end ADDR-AUX-CC
Intercom module - RTS each end ADDR-AUX-RTS
Power Supply
Description Part Number
Universal AC to DC power supply for intercom modules.
• Included with TNR-BP-ICM-8
ADAP-AC30V-X4
Redundant AC to DC power supply for main frame, 12 VDC output ADAP-AC12V-DIN
Cables
Description Part Number
Thunder Audio Out Breakout Cable, DB25M, 8 XLR3 Male CA-D25F-8XLR3M
Thunder Audio In Breakout Cable, DB25M, 8 XLR3 Female CA-D25M-8XLR3F
Thunder Audio interconnect cables, DB25M to DB25M, 40cm length CA-D25MM-40
Thunder Audio interconnect cables, DB25M to DB25M, 80cm length CA-D25MM-80
Thunder Data/GPI interconnect cable, HD26M to HD26F, 80cm length CA-HD26MF-80
4
Introduction to Thunder
System Components
Fiber Connector Plates
Description Part Number
Fiber connector plates with dual fibers; use for non-redundant systems and redundant systems
with WDMs:
2 ST fiber connectors UFP-2ST
2 SC fiber, ultra polished UFP-2SC
2 SC fiber, angle polished UFP-2SCA
Dual LC connector UFP-2LC
Fiber connector plates with dual fiber connector; use for non-redundant systems only
Neutrik OpticalCon Duo 2 Fibers UFP-NOC2
MX dual fiber UFP-MX2
Neutrik OpticalCon Quad 4 Fibers UFP-NOC4
Fiber connector plates with quad fiber connectors; use for redundant systems without WDM
4 ST fiber connectors UFP-4ST
4 SC fiber, ultra polished UFP-4SC
