31
Technical Details
Chapter 6 provides electrical and mechanical specifications for the NV9604.
Topics
Power Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
NV9604 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Power Specifications
NV9604 Power Specifications
NV9604 Specifications
NV9604 Physical Specifications
Specification Detail
AC power 90–250 VAC, 50–60 Hz, auto-sensing.
Inrush current < 50 A at 230 VAC, cold start, at 25 °C,
Input current < 2.0 A rms at 115 VAC; < 1.0 A at 230 VAC.
Power consumption
< 14W
Regulatory UL listed and CE compliant.
Specification Detail
Dimensions Height: 1.72 in (43.7.9 mm), fits EIA 1 RU (1.75 in or 44.5 mm),
Width: 19.0 in (482.6 mm).
Depth: 8.61 ± 0.01 in (218.7 mm), enclosure, 9.14 in (232.2mm) overall.
Requires approximately. 3 in cable clearance.
Weight 7.6 lb (3.447 kg).
Connectors Power: AC.
Ethernet: 1 connector, 10baseT, RJ-45 jack.
RS-232: 1 connector, 9-pin D type, for diagnostics and upgrades.
Grounding terminal None.
