Otherwise, the second button will remain amber, indicating a panel error. These are the poten-
tial panel errors:
You can now prepare an NV9604 configuration in NV9000-SE Utilities and upload the configura-
tion to the NV9604. You need a panel ID to create a NV9604 configuration. When you upload the
configuration, the panel ID you entered in NV9000-SE Utilities designates the actual panel to
which the upload will occur. If no actual panel has that ID, the upload cannot occur.
Setting the Panel ID
 It is not possible to set the panel ID of an NV9604 at the panel itself. You must use NV9000-SE
Utilities to set the panel ID.
Follow these steps to set the panel ID.
1 If you have more than one NV9604 to set up, choose one of them.
2 Apply power to the panel. Connect one panel to the appropriate panel/router network of
your system controller.
3 In NV9000-SE Utilities, click ‘System Management’ in the navigation pane. Click the “+” sign
next to the icon for the applicable system in the ‘System management’ tree at the left. Doing
that expands the information “tree” associated with the system. Then click the
‘Control Panels ...’ entry in the tree.
Error Solution
The panel ID is incorrect Set the panel ID in NV9000-SE Utilities.
The panel is disconnected from the NV9000 sys-
tem Make sure that the panel is connected to an Ether-
net switch that supports 10baseT and that the
Ethernet switch is connected to the systemk con-
troller’s panel and router net.
The panel has a panel ID already assigned to
another panel. Set the panel ID in NV9000-SE Utilities.
