58 KAYENNE — Installation Planning Guide
Section 4 — System Cabling
Factory Default Network Settings
To integrate Kayenne devices into an existing network, ask the local
network administrator for that network’s subnet mask. Before changing IP
addresses always set the subnet masks of the Kayenne devices to the mask
of the local network.
Control Surface Cabling
Connectors on the outside bottom of the Control Panel tray connect to
numbered ports on the PCU, using special multi-pin cables that carry both
power and communications signals. Special cables are also used to connect
the Menu Panels to the PCU.
CAUTION Do not connect or disconnect the multi-pin cables linking a Kayenne Control
Panel tray or Menu Panel to the PCU while the PCU is powered up. Damage
to the Kayenne equipment can result.
Table 2. Kayenne System Default IP Addresses
Device IP Address
Video Processor Frame CPU 192.168.0.170
Image Store CPU 192.168.0.171
Control Panel Surface 1A 192.168.0.173
Touch Screen Menu Panel 1 192.168.0.175
Touch Screen Menu Panel 2 192.168.0.176
Control Panel Surface 1B 192.168.0.177
Control Panel Surface 2A 192.168.0.178
Control Panel Surface 2B 192.168.0.179
32-Crosspoint Remote Aux Panels
V1.6.5 and higher software:
(hard reset with the front panel buttons)
IP Address: 192.168.1.2
Frame IP: 192.168.1.1
Gateway IP: 192.168.1.1
Subnet Mask 255.255.255.0
Note 32-Crosspoint Remote Aux Panel default settings must
be changed to operate with a Kayenne system whose
other components are configured with their default IP
addresses.
All Subnet Masks) 255.255.255.0
All Gateways
(except V1.6.5 software Remote Aux panel) 192.168.0.1
Reserved For Future Use
CAUTION Do not connect any devices configured with the fol-
lowing IP addresses to a Kayenne network.
Video Processor Frame Gigabit Ethernet 192.168.0.172
PCU Panel Reserved LAN Port 192.168.0.174
