KAYENNE — Installation Planning Guide
21
Control Panel Assembly
4-ME 25 Control Panel
Control panels with 25 source selection buttons are narrower in width, but
otherwise have the same dimensions as 35 source button models.
Figure 15. 4-ME 25 Control Panel Dimensions
1341.7 mm
52.8 in.
621.5 mm
24.5 in.
4-ME 25 Flat Installation
1309.5 mm
51.6 in.
124.0 mm
4.9 in.
275.0 mm
10.8 in.
4-ME 25 Curved Installation
