Page 48
48
KAYENNE — Installation Planning Guide
Section 3 — Kayenne Frames
4-RU Frame Power Supplies
The 4-RU Kayenne Video Processor frame has one power supply standard.
An additional power supply is available as an option for redundancy. It
slides into the extra power supply slot in the chassis. When equipped with
the redundant power supply option, the frame will continue to operate
without interruption should a single power supply fail.
Panel Control Unit (PCU) Installation
PCU Dimensions
Figure 50. Panel Control Unit Dimension (Front View)
483 mm
19.0 in.
132.6 mm
5.22 in.
8623266_09
