10
ENGLISH
Preparing the projector for operation
Orientation of the projector
Picture size can be set by changing the distance between the screen and the projector.
Front projection
To find the approximate distance
between the projector and screen:
Multiply the width of the screen
x 1.875 ~
1.975 (max.) ,
Multiply the width of the screen
x 2.468 ~
2.57 (min.) ,
• Refer to the chart to recom-
mended distances in maximum
zoom and minimum zoom.
Diagonal size
(inch)
40 "
60 "
80 "
100 "
120 "
140 "
160 "
180 "
200 "
300 "
Height inches
(inch)
24 "
36 "
48 "
60 "
72 "
84 "
96 "
108 "
120 "
180 "
Width feet
(inch)
32 "
48 "
64 "
80 "
96 "
112 "
128 "
144 "
160 "
240 "
Screen Distance from screen (L) / (approximate)
Maximum
zoom (min.)
(mm)
1527
2335
3143
3951
4758
5566
6374
7182
7990
12029
(mm)
2012
3062
4112
5162
6213
7263
8313
9363
10413
–
(inch)
60.12"
91.93"
123.74"
155.55"
187.32"
219.13"
250.94"
282.75"
314.57"
473.58"
(inch)
79.21"
120.55"
161.89"
203.23"
244.61"
285.94"
327.28"
368.62"
409.96"
–
Height projected
image (H)
/ (approximate)
(inch)
3.0"
4.49"
5.98"
7.52"
9.02"
10.51"
12.0"
13.5"
15.0"
22.52"
(mm)
76
114
152
191
229
267
305
343
381
572
SCREEN
Front projection, ceiling mount
For ceiling mount, you need the ceiling mount metal
etc. Also ask specialist for installation. For more
detail, ask your dealer.
• When the use of ceiling mount, set IMAGE
REVERSE in INSTALLATION menu to INVERT.
You can not use KEYSTONE when IMAGE
REVERSE is INVERT. See Page 20.
• Projected images may appear darker when the
unit is used as a ceiling installation than when it
is used in the tabletop position. This does not
signify a product malfunction.
Rear projection
Also ask specialist for installation. For more detail,
ask your dealer.
Minimum
zoom (max.)
SCREEN
• For rear projection, set IMAGE REVERSE in
INSTALLATION menu to MIRROR. See Page 20.
Caution:
• Placing the projector on a carpet reduces ventila-
tion from the fan on the bottom and might cause
problems. Place a hard board or similar item
under the projector to facilitate ventilation of the
unit.
• Place the projector more than 20 in. from the wall
to prevent blocking the intake, exhaust slots and
ventilation of this projector because hot air comes
out of it.
• Do not use the projector under the following
circumstances, which may cause fire or electric
shock.
• in a dusty or humid place
• while the projector is lying sideways or upside
down.
• near a heater
• in a kitchen or oily, smoky or damp place
• in direct sunlight
• where the temperature is lower than 41
°
F or
higher than 95
°
F
Important:
• Do not put stress on the lens or focus ring, as this
may damage them.
• Keep your room dark while using the projector. The
image cannot be seen clearly in a bright place.
L (between the screen and center
of the head of the lens-barrel)
H
(height)
screen
