27
KMV-3901/KMV-3911
Guide to Installation and Operation
Reference
GPI I/O
Audio SMPTE 299M (limited to one pair, embedded on group 1, pair 1)
Cable length 100 m (328 feet) for 3G or HD, 256 m (840 feet) for SD (Belden 1694A)
Alignment jitter
(100 KHz)
< 0.2 UI
Connector DIN 1.0/2.3
HD-SDI monitoring outputs (2) (continued)
Internal Universal Reference from the Densité frame
Note: If your housing frame is referenced, then all KMV-3901/3911
cards within the frame must have their output heads configured with
a refresh rate that matches the reference signal’s refresh rate.
GPI inputs (8)
Description Contact closure to GND
Pull-up voltage 3.3 Volts
Source current 30 μA when input shorted
Low-level activation 0.8 Volts max
Over voltage 24 Volts max
Connector Terminal block interface PCB via DB-26
GPI outputs (2)
Description Contact closure to GND
Signal Open collector 5 to 12 VDC
Contact closure current 50 mA max
Reverse voltage -15 Volts max
Reverse current -50 mA max
V out low 0.6 Volts at 1.5mA
Connector Terminal block interface PCB via DB-26
