19
KMV-3901/KMV-3911
Guide to Installation and Operation
The lists may contain some or all of the following options:
iControl maintains a log of alarm events associated with the card. The log is useful for
troubleshooting and identifying event sequences. Select the Log events check box to
enable logging of alarm events for an individual alarm.
At the bottom of the window are several other controls.
Overall alarm and GSM contribution follow card LED
Select the check box to force the overall alarm and GSM contribution to be identical to the
Card LED status:
• All Overall alarms for which there is a Card LED alarm will be forced to match the Card
LED alarm.
• All Overall Alarms for which there is no Card LED alarm will be Disabled.
A message prompts you to confirm the action, since it will result in changes to the
configuration window that cannot readily be undone.
Copy to other cards
Click Copy to other cards to open a window that allows the alarm configuration set for this
card to be copied into another KMV-3901/3911 card. Select one or more destination cards
from the list in the window by selecting the corresponding check boxes, or all of them by
selecting the All check box.
The alarm makes no contribution (black icon)
The alarm is of minor importance (yellow icon)
The alarm is of major importance (orange icon)
The alarm is of critical importance (red icon)
The alarm exists but has no effect (used for text and composite alarms)
TIP
Click one of the Set all buttons beside a section heading to assign the same
level to all alarms in that section of the column at once.
