Removing and replacing FRUs
Field Replaceable Units (FRUs) are modular hardware components that can be serviced without
disturbing other components in the system.
The pictures in the following topics show how to disassemble. Unless otherwise documented,
re-assembly is the reverse.
To complete all FRU procedures, the following tools are required:
• Torx tool with T15 magnetic tip. This is the only tool needed for most FRU procedures. If
additional tools are required, they are listed with the FRU procedure.
• #1 Phillips screwdriver
• #2 Phillips screwdriver
• 3/16” nut driver
• 1/4” nut driver
• Side cutters
NOTE: Only Grass Valley components are supported. Do not attempt to use components procured
from a different source.
NOTE: Do not discard any hardware unless specifically instructed to do so.
WARNING: To avoid serious injury from high currents, ensure that both power cords are
disconnected prior to removing or replacing any parts.
CAUTION: This system contains board-level components that must be protected from static
discharge and physical shock. Wear a wrist strap grounded to the system chassis when handling
system components.
External Parts Removal
All the parts in this category can be removed and replaced without opening the K2 Solo 3G system
cabinet.
