Grass Valley K2 Dyno PA v.2.0 - Manual (Page 37)

The selected keyword category displays.
Tip: The displayed keyword pane is the one deleted. Make sure the correct
keyword category is displayed before proceeding.
2. Right-click in the keyword category pane and select Delete Tab .
A confirmation message displays.
3. Click Yes .
Using Dyno keyword categories
You can access imported Dyno keywords in categories and subcategories. These
keywords can be accessed by selecting a tab in the Quick Logging pane.
1. In the Quick Logging pane, click on a Dyno keyword category. Dyno keyword
subcategories are indicated by a folder icon.
2. To return to the top level of keyword categories, click on the Home button.
Exporting K2 Dyno PA keywords
You can save all the keywords, and all the keyword categories, in a Dyno-specific
XML file that can be imported into a K2 Dyno Replay Controller or to another K2
Dyno PA PC.
1. Right-click on the Quick Logging pane and select Save/load | Save Dyno XML .
The Select Location for Dyno Keywords Export dialog box displays.
2. Browse to the location where you want to save the XML file.
3. Enter a name and click Save .
Importing keywords
You can import K2 Dyno Controller or K2 Dyno PA keywords from an XML file.
You can also import a backup set of keywords.
1. Right-click on the Quick Logging pane and select Save/load | Load Dyno XML .
The Select Dyno Keywords File dialog box displays.
2. Browse to the location of the XML file, select it and click OK .
The keywords, and the keyword categories, appear in the Quick Logging pane.
13 June 2011 Dyno Production Assistant User Manual 37
Logging and keywords
