8949MDA-CFR/-SFR—Instruction Manual 39
Specifications
Specifications
Table 6. 8949MDA-CFR and 8949MDA-SFR Specifications
Parameter Value
Coax Input
Number and type of inputs 1 BNC
Input impedance 75 Ohm
Input signal type Serial digital component conforming to the following formats:
• SMPTE 292M for 1080i/50, 1080i/59.94, 720p/50 and 720p/59.94
• SMPTE 259M (270 Mb/s)
Signal level SDI 800 mV p-p ±10% max
Return loss >15 dB 0.004 to 1.50 GHz
Equalization Auto equalizing:
HD signals up to 125m of Belden 1694A
SD signals up to 330m of Belden 1694A
Tolerated input jitter Compliant with the SMPTE 259M (270 Mb/s) and SMPTE 292M standards
Fiber Inputs
Connector type One LC (IEC 61754-20)
Number of inputs Up to 2 optical inputs
Fiber type Single mode, complying with ANSI/TIA/EIA-492CAAA (class 1Va dispersion
-unshifted, 9/125 micron step index (SI) fiber)
Maximum attenuation of 1.0 dB per kilometer at 1310 nm
Minimum input power - 20 dBm to 0 dBm
Signal type The same bit rates and format as the coax input
Fiber length Up to 10km for bit rates up to 270 Mb/s
Up to 5km for bit rates up to 1.485 Gb/s
Tolerated input jitter Compliant with the SMPTE 259M (270 Mb/s) and SMPTE 292M standards
DA Coax Outputs
Number and type of outputs 4 BNCs
Output impedance 75 Ohm
Signal type Serial digital component conforming to the following formats:
• 1080i/50, 1080i/59.94, 720p/50 and 720p/59.94
• SMPTE 259M (270 Mb/s)
Signal level SDI 800 mV p-p ±10%
Return loss >15 dB 4 to 270 MHz
>13 dB 0.27 to 1.50 GHz
Output jitter For input with < 0.1 UI jitter, the output jitter complies with the SMPTE 292M
and SMPTE 259M standards
Downscaled Serial Outputs (8949MDA-SFR Module)
Number and type of outputs 4 BNCs
Signal type Conforming to the SMPTE 259M standard
SDI level 800 mV±10%
Return loss > 15 dB
Output jitter Conforming to the SMPTE 259M standard
Downscaler delay < 0.95 ms
Downscaler output 9 bits representation
Embedded audio and HANC passed
to output SD SDI only
