2000NET Instruction Manual 21
Alarms and SNMP Monitoring
SNMP Trap severity can be one of three degrees:
• Warning – a limitation in the module’s intended performance,
• Alarm – a failure in communication with the module, or
• Informational – a configuration change such as a switch setting.
The enabled SNMP traps will be reported to any SNMP manager that is
identified as an SNMP Report Destination in 2000NET configuration (see
2000NET Configuration Web Page on page 34 . Trap severity is read-only
hard-coded information that is interpreted and responded to by the SNMP
Manager software configuration.
The SNMP traps available on the Kameleon 2000 frame and modules are
outlined in
Table 4 . The web page location for the enable/disable controls
are listed as well as the SNMP trap reports available and their severity.
For the latest MIB (Management Information Base) files for the modular
control system, go to the Thomson Grass Valley public ftp site at:
ftp://ftp.thomsongrassvalley.com/pub/modular/
Table 4. 2000/Kameleon Control System SNMP Traps Summary
Function Web Page Control SNMP Trap Report Trap Severity
2000 Frame Frame Configuration
Frame Bus Status Alarm
Fan Status Alarm
Always enabled, no disable Frame Over Temperature Alarm
Frame Power Sled 1 and 2 Power Sled Configuration
PS 1 Fault Alarm
PS 2 Fault Alarm
Sled Removed Warning
Fan Status Alarm
Fan Sled Fan Sled Configuration
Fan Sled Removed Warning
Fan Status Alarm
2000NET Module 2000NET Configuration
Net Card Status Alarm
Hardware Switch Informational
Media Modules Media Module Slot Config
Slot Fault Alarm
Module Removed Warning
Signal Loss Warning
Reference Loss Warning
