Airaid 1006 - Manual

Parts List
#1 ECONOAID x1
#2 Gasket x1
1. Disconnect the negative battery cable!
A.) Slide the red tab, and squeeze the black tab on the mass
air sensor connector, and disconnect it from the sensor. B.)
Push the green tab on the connector and disconnect the crank-
case breather hose from the intake tube. Remove five bolts on
the factory intake tube and remove it from the vehicle. There
are four on the sides of the airbox, and one on the tube near
the power steering reservoir.
2. Remove the four bolts that hold the throttlebody to the intake
manifold.
Thank you for purchasing the ECONOAID Throttlebody Booster. Please read the instruction manual carefully before pro-
ceeding with the installation. Contact ECONOAID @ (888) 876-4676 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit
or instructions that are not clear to you. Your ECONOAID Throttlebody Booster was carefully inspected and packaged. Check that
no parts are missing, or were damaged during shipping. If any parts are missing, please contact ECONOAID.
Tools Required For Installation
5/16”, 10mm Socket
Ratchet and Extension
Part Number 1006
2004-10 Ford F-150
2005-10 F-250, F-350
2005-14 Ford Expedition
2006-08 Lincoln Mark LT
2007-14 Lincoln Navigator
V8 5.4L
A.
B.
U.S. Pat. #7,665,442
