Airaid 300-626 - Manual

Parts List
#1 Poweraid Spacer x1
#2 6mmx57mm Bolt x4
#3 6mm Flat Washer x4
#4 Fiber Gasket x1
Tools Required For Installation
5/16”, 10mm Socket
Ratchet and Extension
Installation Instructions
Part Number 300-626
2008-2012 Dodge Ram
4.7L V8
1. Disconnect the negative battery cable!
A.) Disconnect the intake air temperature sensor.
B.) Loosen the hose clamp that secures the flexible intake tube
to the resonator.
C.) Loosen the bolt that secures the resonator to the intake man-
ifold. Remove the resonator from the vehicle by lifting up on
the front, and then pulling it towards the front of the vehicle.
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the instruction manual carefully before proceed-
ing with the installation. Contact AIRAID @ (800) 498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or instruc-
tions that are not clear to you. Your Poweraid Throttle Body Spacer was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, please contact AIRAID.
2. Remove the four bolts that secure the throttlebody to the
intake manifold. Remove the throttlebody from the intake man-
ifold and set it aside. (No need to disconnect the wiring har-
ness.)
A.
B.
C.
Included with your Airaid Intake System is a sticker with a California Air Resources Board (C.A.R.B.) Executive
Order (EO) number. This sticker must be placed in plain view inside of the engine compartment. Failure to do so
may prevent you from passing a smog inspection.
The C.A.R.B. E.O. number for this
part number includes the vehicles
listed above thru the 2009 model year.
All others are pending.
