Airaid 250-634 - Manual

Parts List
#1 Poweraid Spacer x1
#2 6mmx50mm Bolt x4
#3 6mm Flat Washer x4
#4 Fiber Gasket x1
Tools Required For Installation
5/16”, 10mm Socket
Ratchet and Extension
Installation Instructions
Part Number 250-634
2010-15 Chevrolet Camaro
6.2L V-8
1. Disconnect the negative battery cable!
Remove the oil fill cap and set it aside.
Lift straight up on the engine beauty cover and set it aside.
Reinstall the oil fill cap after the beauty cover has been re-
moved to prevent any foreign material from entering the crank-
case.
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the instruction manual carefully before proceed-
ing with the installation. Contact AIRAID @ (800) 498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or instruc-
tions that are not clear to you. Your Poweraid Throttle Body Spacer was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, please contact AIRAID.
2. Disconnect the breather hose elbow by pulling it straight
away from the intake tube. It is only held in place by an O-ring.
Loosen the two hose clamps that secure the intake tube to the
throttlebody, and the air box lid.
Remove the air intake tube.
