Airaid 100-250 User Manual
Page 2
Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
13. Secure the Air Dam tab to the inner fender using the
two Self drilling screws (#8).
10. Drill 1/8” pilot holes into the inner fender.
11. Install the Weatherstrip (#7) onto the Airdam
12. Install the assembly into the inner fender. Rein-
stall the fender support on top of the Airaid brackets
and secure using the factory hardware. Reinstall the
fender bolt removed in step 7.
14. Connect the performance airbox assembly to
your throttle body or carburetor by using any combi-
nation of Airaid’s UBI components.
PN
100-300
3.0” UBI Tube Only
PN
100-350
3.5” UBI Tube Only
PN
100-400
4.0” UBI Tube Only
Go to www.airaid.com for a complete list of compo-
nents for a custom install.
REV.1.2.14
UBI intake kits consist of multiple angles and straights,
which you cut as desired. Thousands of intake varia-
tions are possible! Available separately, as tubes only,
or individual components including ; couplers,
clamps, brackets and hardware.
For your Oiled media filter we
suggest using the AIRAID Filter
Tune-Up Kit!
Synthamax Air Filters do not require oil.
Service air filter as needed by cleaning
with common non-petroleum all-purpose
household cleaner and water. Simple
Green®, Formula 409® or equivalent
works great. Apply cleaner to outside of
air filter and allow to soak. Then flush
filter clean from the inside out with a gar-
den hose and repeat steps if necessary.
Do not apply high pressure water or air
to clean filter. Allow filter to air dry and
reinstall
.
Thank you for purchasing the Airaid UBI System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST weekdays for questions regarding fit or instructions that
are not clear to you. Your Airaid UBI System was carefully inspected and packaged. Check that no parts are missing, or were damaged during shipping. If any parts are miss-
ing, contact Airaid. The air filter element is protected from direct exposure to water and debris; care should be taken not to drive through deep water. WATER INGESTION IS
THE DRIVERS RESPONSIBILITY! The air filter is reusable and should be cleaned periodically.
FILTER IDENTIFICATION
700-461 Airaid Oiled Media 701-461 Airaid SynthaMax Dry Media - Red
702-461 Airaid SynthaMax Dry Media - Black 703-461 Airaid SynthaMax Dry Media - Blue
8. Position the airbox assembly into the inner fender
area. Check for clearance and adjust the panels and
brackets for fit, and tighten all hardware, final tight.
7. Remove the fender brace and the rear fender bolt on
the core support. Passenger side installations require
relocation of the battery and tray.
9. Using a spring loaded punch, mark inner fender where
the holes will be drilled for the Aid Dam tab.
