Airaid 311-770 - Manual (Page 2)

Installation Instructions. Read Me!
1. Disconnect the negative
battery cable. Loosen hose
clamp on air cleaner box lid.
Carefully twist and remove the
breather hose from the lid.
2. Remove oil fill cap and set
aside.
3. Carefully lift the engine cover
for access to the throttle body.
(There are only grommets that
hold down the cover, no
bolts.)
4. A.) Using the 10mm socket,
remove the bolt that holds the
stock intake system. B.)
Loosen the hose clamp that
holds the coupler to the
throttle body.
5. Carefully pull the intake
towards you and rotate it so
the bottom faces you, and cut
the tie wrap that holds the
breather tube, as shown.
6. Slide the clip off of the intake
tube that holds the breather
line.
7. Carefully twist and remove the
temperature sensor from the
stock intake tube. Remove the
stock intake tube from the
vehicle.
8. If you purchased an Airaid Jr.
Kit, unhook the two clips and
remove the factory air filter,
and replace it with the Airaid
Premium Filter supplied in the
kit.
9. Reconnect the breather hose.
Install the hump hose and two
#60 hose clamps as shown. Do
not tighten the clamps.
A.
B.
