Airaid 520-538 - Manual

Parts List
#1 Poweraid Spacer x1
#2 O-Ring x1
#3 6mm x 70mm Hex Bolts x4
#4 6mm Flat Washers x4
Tools Required For Installation
5/16” & 10mm Sockets
5mm Allen Wrench
Ratchet & Extension
Installation Instructions
Part Number 520-538
Poweraid Spacer For
2004-14 Nissan Titan/Armada
2004-2010 Infinity QX56
5.6L V-8
1. Disconnect the negative battery cable!
Using a 10mm socket, remove the two bolts at the
front of the engine beauty cover. Remove the
engine beauty cover by lifting up and releasing it
from the grommets. 2. Using a 5/16” socket, loosen the hose clamp on
the throttle body end of the factory air intake tube.
Move the factory air intake tube up and out of the
way of the throttle body. Using a 5mm allen
wrench, remove the 4 bolts that hold the throttle
body to the intake manifold.
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the in-
struction manual carefully before proceeding with the installation. Contact AIRAID @ (800)
498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or instructions that
are not clear to you. Your Poweraid Throttle Body Spacer was carefully inspected and
packaged. Check that no parts are missing, or were damaged during shipping. If any
parts are missing, please contact AIRAID.
Thank you for selecting AIRAID.
