Airaid 510-608 - Manual

Parts List
#1 Poweraid Spacer x1
#2 8mmx80mm Bolts x4
#3 8mm Flat Washers x4
#4 Fiber Gasket x1
Tools Required For Installation
10mm, 12mm, 13mm Sockets
Ratchet and Extension
Pliers
Installation Instructions
Part Number 510-608
Poweraid Spacer For
2003-09Toyota Camry 2.4L
2005-09 Scion tC 2.4L
2008-09 Scion xB 2.4L
1. Disconnect the negative battery cable!
A). Loosen the hose clamp that holds the factory
intake tube to the air cleaner lid. B). Loosen the
two bolts that hold the lid of the air cleaner to the
base. C). Disconnect the wiring harness from the
mass air sensor. 2. Carefully remove the lid, turn it over, and pinch
the two tabs together to remove the plastic wiring
harness holder from the lid (If equipped). Now re-
move the lid from the vehicle and set it aside, it will
be reinstalled later.
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the instruction
manual carefully before proceeding with the installation. Contact AIRAID @ (800) 498-6951 8:00 AM -
5:00 PM MST Weekdays for questions regarding fit or instructions that are not clear to you. Your
Poweraid Throttle Body Spacer was carefully inspected and packaged. Check that no parts are miss-
ing, or were damaged during shipping. If any parts are missing, please contact AIRAID.
3. Reach down behind the engine with your pliers,
and squeeze this clamp, and remove the intake tube
from the throttle body. 4. Using a 12mm socket, remove four bolts that
hold the throttle body to the intake manifold.
A.
B.
C.
