Airaid 510-607 - Manual

Parts List
#1 Poweraid Spacer x1
#2 6mmx70mm Bolt x4
#3 6mm Flat Washer x4
#4 Fiber Gasket x1
Tools Required For Installation
10mm Socket
Ratchet and Extension
Vice Grip Pliers
(Stud Removal)
Installation Instructions
Part Number 510-607
Poweraid Spacer For
05-06 Toyota Tundra/
Sequoia 4.7L
1. Disconnect the negative battery cable!
Remove two 10mm nuts that hold the beauty cover
to the engine. Set the beauty cover and nuts aside
for re-installation later. Loosen the hose clamp that
holds the intake tube to the air filter box. 2. Loosen the hose clamp that holds the intake tube
to the throttle body. Remove and save the bolt that
holds the air conditioning line to the intake tube.
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the in-
struction manual carefully before proceeding with the installation. Contact AIRAID @ (800)
498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or instructions that
are not clear to you. Your Poweraid Throttle Body Spacer was carefully inspected and
packaged. Check that no parts are missing, or were damaged during shipping. If any
parts are missing, please contact AIRAID.
Thank you for selecting AIRAID.
