# 510-566 INSTALLATION INSTRUCTIONS
00-02 Tundra 4.7L
01-02 Sequoia 4.7L
98-02 Land Cruiser, LX470 4.7L
Parts List
(1) Power Plate
(3) “O” Rings
(2) 8mm x 100mm Bolts
(2) 8mm x 70mm Bolts
(4) Washers
(2) 8mm Linkage Plates
(2) 8mm x 30mm Bolts
(2) 8mm x 12mm Bolts
(1) 6mm Linkage Plate
(1) 6mm x 16mm Flat Head Screw
Tools List
13mm Socket
3mm Hex Key
Standard Screwdriver
Thank you for purchasing the PowerAid Throttle Body Spacer. Please read the
instruction manual carefully before proceeding with the installation. Contact AIRAID @
(800) 498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or in-
structions that are not clear to you. Your PowerAid Throttle Body Spacer was carefully
inspected and packaged. Check that no parts are missing, or were damaged during
shipping. If any parts are missing, please contact AIRAID.
Thank you for selecting AIRAID.
Included with your Poweraid Spacer is a sticker with a California Air Resources Board
(C.A.R.B.) Executive Order (EO) number. This sticker must be placed in plain view inside of
the engine compartment. Failure to do so may prevent you from passing a smog inspection.
