Airaid 450-636 - Manual

Parts List
#1 Poweraid Spacer x1
#2 6mmx75mm Bolt x4
#3 6mm Flat Washer x4
#4 Gasket x1
#5 Speed clamp x2
#6 3/8” x 2- 3/4” Hose x1
Tools Required For Installation
8mm, 10mm Socket
Ratchet and Extension
Pliers
Installation Instructions
Part Number 450-636
2011 –14 Ford Mustang
2011 –13 Ford F-150
3.7 l V-6
Note: Because of space constraints, this
Poweraid spacer can not be used in con-
junction with Airaid intake system 450-265.
1. Disconnect the negative battery cable!
A.) Disconnect the breather line or lines, from the Factory in-
take tube.
B.) loosen the clamps securing the intake tube to the throttle-
body and the airbox.
C.) Remove the Factory intake tube and set aside.
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the instruction manual carefully before proceed-
ing with the installation. Contact AIRAID @ (800) 498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or instruc-
tions that are not clear to you. Your Poweraid Throttle Body Spacer was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, please contact AIRAID.
2. Using pliers, open the spring clamps and slide off of the
factory breather hose, and onto the hard line.
A
B
B
C
