Airaid 450-603 - Manual

Parts List
#1 Poweraid Spacer x1
#2 6mm x 60mm Screw x4
#3 6mm Washer x4
#4 Gasket x1
Installation Instructions
Part Number 450-603
FORD F-150 PICKUP 2011-201
4
3.5L V6 EcoBoost
1. Disconnect the negative battery cable!
Locate and loosen the intake tube clamps. Remove the
factory intake tube and set it aside. It may be necessary to
remove the engine cover to gain access to the throttle
body on some applications.
.
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the instruction manual carefully before proceed-
ing with the installation. Contact AIRAID @ (800) 498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or instruc-
tions that are not clear to you. Your Poweraid Throttle Body Spacer was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, please contact AIRAID.
2. Loosen the clamp on the throttle body inlet tube and
slide it away from the throttle body. Remove the four
bolts that secure the throttle body to the intake manifold.
