Airaid 400-614 - Manual

Parts List
#1 Poweraid Spacer x1
#2 6mmx50mm Bolts x4
#3 6mm Flat Washers x4
#4 Fiber Gasket x1
Tools Required For Installation
8mm & 10mm Socket
Ratchet and Extension
Installation Instructions
Part Number 400-614
Poweraid Spacer For
05-07 Ford F 250/ F-350
6.8L V-10
1. Disconnect the negative battery cable!
Push the green locking tab on the factory breather
hose, and disconnect it from the intake tube. Loosen
the two hose clamps at each end of the factory in-
take tube. Remove the tube from the throttle body,
and the factory air cleaner, and set it aside. 2. Using a 8mm socket, remove four bolts that hold
the throttle body to the intake manifold.
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the in-
struction manual carefully before proceeding with the installation. Contact AIRAID @ (800)
498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or instructions that
are not clear to you. Your Poweraid Throttle Body Spacer was carefully inspected and
packaged. Check that no parts are missing, or were damaged during shipping. If any
parts are missing, please contact AIRAID.
Thank you for selecting AIRAID.
