# 400-588 INSTALLATION INSTRUCTIONS
98-00 Ford Ranger 2.5L
Parts List
(1) Power Plate
(2) Gaskets
(4) 8mm x 50mm Bolts
(4) 8mm Lock Washers
(2) Linkage Plates
(2) 8mm x 16mm Flat Head Screws
(2) Spacers 5/16” thick with 5/16” hole
(2) 5/16-18” x 3/4” Bolts
(1) Rubber Hose 3/8” ID x 2 3/4” Long
Tools List
13mm Socket
5mm Hex Key Wrench
Standard Screwdriver
Thank you for purchasing the PowerAid Throttle Body Spacer. Please read the
instruction manual carefully before proceeding with the installation. Contact AIRAID @
(800) 498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or in-
structions that are not clear to you. Your PowerAid Throttle Body Spacer was carefully
inspected and packaged. Check that no parts are missing, or were damaged during
shipping. If any parts are missing, please contact AIRAID.
Thank you for selecting AIRAID.
