49
Model 648SB Low Profile Clamshell (2 Piece)
92-1146 : Rev. 131230
Parts List, Housing and Motor Assy, Hydraulic (P/N 19-0779 and 56-0044)
19-0469 HOUSING ASSEMBLY, DRIVE 1
1. 19-0466 HOUSING, DRIVE 1
2. 24-1513 PLATE, SHIM 2
3. 29-0093 BEARING, BALL 1
4. 33-0071 SCREW, CAP 2
5. 33-0074 SCREW, CAP 4
6. 33-0513 SCREW, SET 1
7. 33-0352 SCREW, FLAT HEAD 4
8. 39-0506 GEAR, PINION 1
56-0044 MOTOR ASSEMBLY, HYDRAULIC 1
9. 31-0001 KEY, WOODRUFF 1
10. 33-0107 SCREW, CAP 2
11. 54-0002 ADAPTER 2
12. 54-0294 COUPLER, QD, BODY 1
13. 54-0295 COUPLER, QD, TIP 1
14. 55-0156 HOSE ASSEMBLY, HYDRAULIC 2
15. 56-0043 MOTOR, HYDRAULIC 1
NOT SHOWN
54-0114 CAP, DUST 1
54-0115 PLUG, DUST 1
REFERENCE: Hose Manifold Assemblies to connect the Dual Hydraulic Motors
55-0169 HOSE ASSEMBLY, MANIFOLD, FEMALE 1
55-0170 HOSE ASSEMBLY, MANIFOLD, MALE 1
Item Part
No. No. Description Qty
