Raptor Drivers for Linux Installation and Reference Manual
A-4
A.2 T-Class
Products
A.2.1 Raptor 2100T Specifications
Frame Buffer:
64MB SGRAM; 100 MHz
MOX Hardware:
Tech Source MOX ASIC; 32 layer
Priority
Management,
2 blending layers
Hardware Cursor: Up to 3 cursors
Color Lookup
Primary color map with 2048
Tables:
entries and two auxiliary color
maps with 256 entries each
PCI Interface:
33/66 MHz, 32/64-bit
Universal
Signaling
Video Interface:
Red, Green, Blue, at RS-343
(50 ohm)
Video Sync:
Separate sync at TTL levels,
(75
ohm)
Video Connector: DB-5W5
Temperature
10
0
to 50
0
C operating
Rating:
-10
0
to 70
0
C non-operating
Humidity Rating: 5 to 90% (non-condensing)
Power Rating:
+5V @ 5 Amps
Dimensions:
312mm x 107mm (12.28” x 4.2”)
